esf-1/7/CDF/A

IO-Link
Bild vom esf-1-7 Ultraschall-Spleiß- und Etikettensensor
watchlist 0

Downloads

Page content as online catalogue

Download Sensor as PDF

Documentation

User manual

CAD Files

IPT PDF

Approvals and certificates

EU Declaration of Conformity UKCA Declaration of Conformity

IO-Link

IODD-Library IO-Link Accompanying Sheet
  • 1 x Push-Pull + 1 x pnp 1 x Push-Pull + 1 x pnp
fork-like
IO-Link
label/splice detection
sheeting with weights of < 20 g/m2 up to >> 400 g/m2, metal-laminated sheets and films up to 0.2 mm thick, self-adhesive films, labels on backing material
größere Gabelweite/-Tiefe
IO-Link
Smart Sensor Profile
UL Listed

Technical Data - Mechanics

6 mm
86 mm

Ultrasonic-Specific

pulse operation with amplitude evaluation
500 kHz

Electrical Data

20 - 30 V d.c., reverse polarity protection
± 10 %
≤ 50 mA
5-pin M12 initiator plug

Outputs

switching output
label/splice detected
Push-Pull, UB-3 V, -UB+3 V,Imax = 100 mA
NOC/NCC adjustable, short-circuit-proof
switching output
label/splice detected
web break
pnp: Imax = 200 mA (UB-2V)
NOC/NCC adjustable, short-circuit-proof
300 µs up to 2,25 ms, dependent on the material
< 300 ms

Inputs

com input
synchronisation input
teach-in input

Housing

aluminium anodized
polyurethane foam, epoxy resin with glass contents
IP 65
+5°C to +60°C
-40°C to +85°C
80 g
esf-1/15/CDF/A
larger fork width/depth

Technical Features/Characteristics

1 push-button<br/>com input
Teach-in and QuickTeach via push-button
Teach-in via com input on pin 5
LCA-2 with LinkControl
IO-Link
yes
1 x LED green: working, 1 x LED yellow: switch status Pin 4, 1 x LED red: switch status Pin 2
größere Gabelweite/-Tiefe
IO-Link
Smart Sensor Profile
UL Listed

IO-Link

esf-1/7/CDF/A
16953
yes
COM2 (38,4 kBaud)
4 ms
32 Bit PDI
Bit 0: initial state Pin 4; Bit 1: initial state Pin 2; Bit 2: web break; Bit 8-15: scale (Int. 8); Bit 16-31: measured value (Int. 16)
Identification, switched output, add-ons, temperature compensation, operation
SP1 Teach-in, SP2 Teach-in, factory settings
yes
IODD version 1.1

Accessories

KST5A-2/M12
KST5A-5/M12
KST5G-2/M12
KST5G-5/M12
LCA-2
LCA-2 Koffer

Matching sensors

prev
next
KST5A-2/M12

KST5A-2/M12

cable, 5 contacts, female angled connector M12, cable length 2 m
KST5A-5/M12

KST5A-5/M12

cable, 5 contacts, female angled connector M12, cable length 5 m
KST5G-2/M12

KST5G-2/M12

cable, 5 contacts, female cable connector M12, cable length 2 m
KST5G-5/M12

KST5G-5/M12

cable, 5 contacts, female cable connector M12, cable length 5 m
LCA-2

LCA-2

For the convenient setting of a large number of microsonic sensor families. The LinkControl-Adapter LCA-2 can be used to read, copy or write parameters. Additionally, you can connect it with a PC in order to configurate it via LinkControl Software.
LCA-2 Koffer

LCA-2 Koffer

Set for convenient setting of a number of microsonic sensor families.<br/>Contents:<br/>LCA-2<br/>- Adaptor for sensors with cable connection (lcs) incl. cable clamps<br/>- Adapter for power supply incl. cable clamps<br/>- Power supply 90-240VAC/24VDC, 625 mA, with 2,5 m cable<br/>- four exchangeable AC-plugs for use in Europe, USA, Great Britain and Australia<br/>- USB - cable A-plug to B-plug<br/>- USB stick with LinkControl software<br/>- Manual (German / English)
