dbk+4/Sender/M18/K1
Downloads
Page content as online catalogue
Documentation
CAD Files
Approvals and certificates
cylindrical M18
double sheet control
papers with weights of 20 - 2,000 g/m2, Washi, metal-laminated sheets and films up to 0.4 mm thick, self-adhesive films, sheet metals up to 0.3 mm thick, fine corrugated card, wafers, PCBs
transmitter for ultrasonic double sheet control
distance between transmitter and receiver can be selected
cable connection
distance between transmitter and receiver can be selected
cable connection
Technical Data - Mechanics
20 - 60 mm; optimal: 40 mm ± 3 mm
± 45° from the perpendicular to the sheet
Ultrasonic-Specific
pulse operation with amplitude evaluation
400 kHz
7 mm in front of transmitter and receiver
housing
brass sleeve, nickel-plated, plastic parts, PBT
polyurethane foam, epoxy resin with glass contents
IP 65
+5°C to +60°C
-40°C to +85°C
30 g
15 Nm
different cable length
Technical Features/Characteristics
not necessary
not necessary
transmitter for ultrasonic double sheet control
distance between transmitter and receiver can be selected
cable connection
distance between transmitter and receiver can be selected
cable connection
